Docker for JavaScript Devs: How to Containerise Node.js Apps Efficiently

November 26, 2020 - 14 min

Docker is a really cool technology to have applications run the in the same, predictable context, ensuring the “but it works on my machine” comments are a thing of the past. Not to mention how Docker integrates with Docker Compose and Kubernetes for larger-scale applications! But that’s for another day.

In this article, you will learn about some good principles to containerise Node.js apps efficiently. These principles are probably quite general and well-known, but they’re easy to overlook for beginners to Docker and Dockerfiles.

You will need to have Docker and Node.js installed locally to follow along comfortably.

Close shot of a whale-shaped wooden toy
Docker wants to make you happy, Photo by cottonbro from Pexels

Table of contents

Let’s start with a simple Next.js application:

$ npm create next-app --use-npm

and let’s write the following into a file called Dockerfile at the root of the project:

FROM node:14.15.0

WORKDIR /app

COPY . .
RUN npm ci
RUN npm run build

EXPOSE 3000

USER node

CMD ["npm", "run", "start"]

Okay, what just happened? 😄

Docker Glossary

  • FROM <image>: indicates what pre-existing Docker image we want to build upon
  • WORKDIR <some-path-in-the-container>: indicates that our application code will live in a directory inside the container (will be created if the path does not exist)
  • COPY <from-context> <to-container>: copies files from the context the container’s WORKDIR directory
  • RUN <command>: runs a command as part of the docker build process only
  • EXPOSE <port>: it does not do anything more than documenting which port the app uses
  • USER <user>: by default, we executed all the previous command as the default user for the Docker image we chose above (which often is root with superuser privileges); it’s good practice to use a different user to run the app.
  • CMD <command>: the command that will be executed when we run docker run <image-tag>, it is not executed during the build process.

Assuming we have Docker installed, we could now run

$ docker build --tag my-containerised-nextjs-app .

This command kindly asks the Docker daemon running on our machine to build the Dockerfile we just wrote with the files present in the current directry (the .) and to call that image my-containerised-nextjs-app (with the --tag flag).

After the build completed, run

$ docker run --rm -p 3000:3000 my-containerised-nextjs-app

and we should have our app running at http://localhost:3000.

This second command orders the Docker daemon to run the image named my-containerised-nextjs-app with port 3000 on my machine to correspond to port 3000 inside the container so that we can interact with our Next.js app. This port mapping is done through the -p hostPort:containerPort flag. Go ahead and change the port mapping and see if you can still access the app. The --rm flag indicates that we do not want the Docker daemon to keep the container when we stop its execution (with CTRL+C); this is useful not to clog our machines with useless logs while developing.

Voilà, we have containerised our Next.js app. The End. 🎉

Wait! Don’t leave, there’s more! 👇

Optimising a Node.js app’s Docker image

The section above does the job, but it’s not optimal. If we only have so few pipeline minutes and we don’t like wasting resources ♻️, this setup will eat more than is necessary. There are a few strategies to optimise a Dockerfile:

  1. Create a comprehensive .dockerignore file
  2. Use an appropriate base image
  3. Decouple the dependency installation step from application code
  4. Decouple the build from the resulting built application
  5. (Optional) Purge node_modules from unnecessary files

Create a comprehensive .dockerignore file

If we look at the logs from building the Docker image, we could read:

Step 4/8 : RUN npm ci
 ---> Running in 559b499f0e2c
npm WARN prepare removing existing node_modules/ before installation

That means we copied the node_modules folder from our local context over to the Docker image being built. What’s more, npm ci removes them to make sure it works consistently. That is an indication that we should not copy the node_modules in the first place.

To let Docker know some files and folders should be ignored, we can list them in a .dockerignore file. For example, add the following to a file named .dockerignore:

node_modules

Run the build again and the warning disappeared.

What’s more, we can see how much less was sent to the Docker build context:

# BEFORE
$ docker build --tag my-containerised-nextjs-app .
Sending build context to Docker daemon  101.8MB

# AFTER
$ docker build --tag my-containerised-nextjs-app .
Sending build context to Docker daemon  400.4kB

In practice, we would want to add as many files as possible to our .dockerignore to ensure we’re not wasting time and energy on files which won’t be necessary for the build. This can include documentation files (e.g. *.md), configuration files which are only necessary when developing (e.g. .eslint*, .prettier*) as well as our Git history (e.g. .git).

With the following .dockerignore file:

node_modules
*.md
.git

we end up sending the bare minimum to the Docker daemon:

$ docker build --tag my-containerised-nextjs-app .
Sending build context to Docker daemon  248.3kB

Use an appropriate base image

Docker images come in all shapes and sizes. When it comes to building or deploying our app, the smaller the size, the better. For our Next.js app, we don’t need all that’s available in node:14.15.0. For example, we don’t need git or curl. We can instead use the alpine flavour of that image, namely node:14.15.0-alpine.

The difference in size between node:14.15.0 and node:14.15.0-alpine is enormous!

REPOSITORY                    TAG                 SIZE
node                          14.15.0             943MB
node                          14.15.0-alpine      117MB

Our final containerised Next.js app will hence be much smaller thanks to this teeny-tiny modification of our Dockerfile:

- FROM node:14.15.0
+ FROM node:14.15.0-alpine

WORKDIR /app

COPY . .
RUN npm ci
RUN npm run build

EXPOSE 3000

USER node

CMD ["npm", "run", "start"]

For reference, if we want to inspect the size of the Docker images we have available locally, we can run docker image ls --all.

Our Docker image has size 1.05GB if we use node:14.15.0,

REPOSITORY                    TAG                 IMAGE ID            CREATED             SIZE
my-containerised-nextjs-app   latest              c78d43a2c5bc        15 seconds ago      1.05GB

and it drops to 229MB if we use node:14.15.0-alpine instead!

REPOSITORY                    TAG                 IMAGE ID            CREATED             SIZE
my-containerised-nextjs-app   latest              d0746ef6e8a4        21 seconds ago      229MB

Decouple the dependency installation step from application code

Our setup is already much better with a suitable .dockerignore file and with a much leaner base image. However, we haven’t made any changes to our package.json and the npm ci step always needs to run if make any changes to our application code.

This is because Docker caches each step as an intermediate Docker container. For example, if we were to run the build again (docker build --tag my-containerised-nextjs-app .), we would see that the cache is used for all steps, resulting in a nearly instant build (because nothing happened, really 😄):

$ docker build --tag my-containerised-nextjs-app .
Sending build context to Docker daemon  248.3kB
Step 1/8 : FROM node:14.15.0-alpine
 ---> 9db54a688554
Step 2/8 : WORKDIR /app
 ---> Using cache
 ---> d5d4291dc699
Step 3/8 : COPY . .
 ---> Using cache
 ---> b56455e98a93
Step 4/8 : RUN npm ci
 ---> Using cache
 ---> ba4ab784f27e
Step 5/8 : RUN npm run build
 ---> Using cache
 ---> a51c18594a20
Step 6/8 : EXPOSE 3000
 ---> Using cache
 ---> 806dc06cbb6c
Step 7/8 : USER node
 ---> Using cache
 ---> b86db08de717
Step 8/8 : CMD ["npm", "run", "start"]
 ---> Using cache
 ---> d0746ef6e8a4
Successfully built d0746ef6e8a4
Successfully tagged my-containerised-nextjs-app:latest

If we now modify anything in the folder that is not ignored thanks to our .dockerignore file, Docker will have to bust the cache from Step 3 onwards (the “Using cache” expression is not printed any more). Let’s create an empty file and run the build again:

# create an empty file
$ touch file
# build again
$ docker build --tag my-containerised-nextjs-app .
Sending build context to Docker daemon  248.8kB
Step 1/8 : FROM node:14.15.0-alpine
 ---> 9db54a688554
Step 2/8 : WORKDIR /app
 ---> Using cache
 ---> d5d4291dc699
Step 3/8 : COPY . .
 ---> e2b761bb08a6         # The cache is not used anymore
Step 4/8 : RUN npm ci
 ---> Running in b36f2511e117
...

To remedy this and ensure that npm ci runs only when necessary, we can first copy package.json and package-lock.json files, run npm ci, and then bring in the rest of the files to build the project:

FROM node:14.15.0-alpine

WORKDIR /app

- COPY . .
+ COPY package.json .
+ COPY package-lock.json .
RUN npm ci
+ COPY . .
RUN npm run build

EXPOSE 3000

USER node

CMD ["npm", "run", "start"]

After we modified the Dockerfile by applying the diff above, we see that Docker does not leverage the cache at all because the steps are different. This always happens when we modify the layers and/or their order.

However, after running this build for a first time, subsequent builds will be much faster as the npm ci step will use the cache unless we modify package.json or package-lock.json:

# create another file to see when Docker stops using the cache
$ touch another-file
# run the build again
$ docker build --tag my-containerised-nextjs-app .
Sending build context to Docker daemon  249.3kB
Step 1/10 : FROM node:14.15.0-alpine
 ---> 9db54a688554
Step 2/10 : WORKDIR /app
 ---> Using cache
 ---> d5d4291dc699
Step 3/10 : COPY package.json .
 ---> Using cache
 ---> 139b5a611c0b
Step 4/10 : COPY package-lock.json .
 ---> Using cache
 ---> 5bc380de1397
Step 5/10 : RUN npm ci
 ---> Using cache
 ---> dff6b2da4bdc
Step 6/10 : COPY . .
 ---> 08911c09b40f
Step 7/10 : RUN npm run build
 ---> Running in f5374a54d9ad

> my-app@0.1.0 build /app
> next build
...

Decouple the build from the resulting built application

For this section to make more sense, we will create another Next.js app that uses some dev dependencies which are necessary only when building the app but not when running it in production.

$ npm create next-app --use-npm --example with-tailwindcss with-tailwindcss-app

Copy the Dockerfile and .dockerignore files created in the other example into with-tailwindcss-app. Build the Docker image and run it to make sure it’s working well before continuing:

$ docker build --tag with-tailwindcss-app .
$ docker run --rm -p 3000:3000 with-tailwindcss-app

As we can see in the package.json file, we have a few dependencies which are only ever going to be used when building our app. We won’t need them in the final Docker image. So let’s get rid of them!

We are going to leverage multi-stage Docker builds. They sound more complicated than they are :)

Here’s a multi-stage build Dockerfile: in the builder container, we install dependencies and build our app, and in the second stage, we copy relevant files from the builder to our final image and install only production dependencies.

FROM node:14.15.0-alpine as builder

WORKDIR /app

COPY package.json .
COPY package-lock.json .
RUN npm ci
COPY . .
RUN npm run build

FROM node:14.15.0-alpine

WORKDIR /app

COPY --from=builder /app/package.json .
COPY --from=builder /app/package-lock.json .
RUN npm ci --production
COPY --from=builder /app/.next .next

EXPOSE 3000

USER node

CMD ["npm", "run", "start"]

If our app also contained a Next.js config file and a public folder, we would also need to copy them from the builder stage:

...
COPY --from=builder /app/.next .
+ COPY --from=builder /app/next.config.js .
+ COPY --from=builder /app/public public
...

Comparing the sizes, we see that we removed 39MB of dev dependencies, not bad.

  • without multi-stage build
REPOSITORY                    TAG                 IMAGE ID            CREATED              SIZE
with-tailwindcss-app          latest              88089e6f965d        18 minutes ago      269MB
  • with multi-stage build
REPOSITORY                    TAG                 IMAGE ID            CREATED              SIZE
with-tailwindcss-app          latest              ba7307736fb0        25 seconds ago       230MB

(Optional) Purge node_modules from unnecessary files

Finally, to make our Docker image the leanest, we will purge our node modules from all the files which were included by the library authors and aren’t directly useful to our Docker image. For example, documentation files and READMEs, config files for Prettier and such, etc.

Note that this is not without risk as we could be removing files that we actually need to run the application correctly (we had a file named test.js that contained important code and it was mercilessly removed by the tool, which broke the application 😅).

We will add another stage called production-deps to make our node modules go through a diet with node-prune (GitHub repo). The list of files and folders that node-prune will remove is largely inspired by Yarn’s default list (generated through yarn autoclean --init).

To install node-prune, we need curl to be a locally available executable, so we can either choose a base image that contains it out of the box, or we can add it to node:14.15.0-alpine. Because we won’t need anything else, we will choose the latter.

FROM node:14.15.0-alpine as builder

WORKDIR /app

COPY package.json .
COPY package-lock.json .
RUN npm ci
COPY . .
RUN npm run build

+ FROM node:14.15.0-alpine as production-deps

+ WORKDIR /app

COPY --from=builder /app/package.json .
COPY --from=builder /app/package-lock.json .
RUN npm ci --production
+ # Add curl
+ RUN apk --no-cache add curl
+ # Install node-prune https://github.com/tj/node-prune
+ RUN curl -sf https://gobinaries.com/tj/node-prune | sh
+ RUN node-prune /app

FROM node:14.15.0-alpine

WORKDIR /app

+ COPY --from=production-deps /app/package.json .
+ COPY --from=production-deps /app/package-lock.json .
+ COPY --from=production-deps /app/node_modules node_modules

COPY --from=builder /app/.next .next

EXPOSE 3000

USER node

CMD ["npm", "run", "start"]

Try it by building the image once more.

When node-prune ran, it printed out in the console that it removed 12MB:

...
Step 15/24 : RUN node-prune /app
 ---> Running in 69e030ab8b70


         files total 14,269
       files removed 3,722
        size removed 12 MB
            duration 216ms
...

However, suprinsingly, a whopping 32MB were removed in comparison to our previous Dockerfile. (It seems node-prune’s tallying is not totally accurate when I tested locally as it removed 20.7 MB instead — though it still doesn’t explain the other 11.3 MB 🤷‍♂️)

$ docker image ls with-tailwindcss-app
REPOSITORY                    TAG                 IMAGE ID            CREATED              SIZE
with-tailwindcss-app          latest              c5e2081dba30        9 seconds ago        198MB

Let’s ensure our app is running well without the files node-prune removed and we can be on our merry way! 🐳 🎉

Docker build checklist for JavaScript Devs

To summarise what we’ve learnt so far, here’s a small checklist to review our own Docker build setups:

  • I have a comprehensive .dockerignore file
  • I use an appropriate base image
  • I decoupled the dependency installation step to improve caching
  • I decoupled the resulting built application from the build step
  • I purged the node_modules from unnecessary files

Time to flex! 💪 Show me your before and after Docker image sizes in the comments below!
